Vertical Spiral Elevator Conveyor , Spiral Cooling Conveyor For Rock Salt

    Buy cheap Vertical Spiral Elevator Conveyor , Spiral Cooling Conveyor For Rock Salt from wholesalers

    Buy cheap Vertical Spiral Elevator Conveyor , Spiral Cooling Conveyor For Rock Salt from wholesalers
    • Buy cheap Vertical Spiral Elevator Conveyor , Spiral Cooling Conveyor For Rock Salt from wholesalers

    Vertical Spiral Elevator Conveyor , Spiral Cooling Conveyor For Rock Salt

    Ask Lasest Price
    Brand Name : KENI
    Model Number : ZC
    Certification : CE
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 1000PCS
    Delivery Time : 15work days
    • Product Details
    • Company Profile

    Vertical Spiral Elevator Conveyor , Spiral Cooling Conveyor For Rock Salt

    Vertical Vibrating Screw Conveyors / Cooling Spiral Elevator for Rock Salt


    1. Product overview:


    The ZC series vertical elevator is a new type of vertical conveying equipment. This machine can convey all granular, block, and powder solid materials (with low viscosity). It is widely used in metallurgy, coal, building materials, grain, machinery, medicine, food and other industries. It is used for vertical lifting operations of powdery and granular materials. The elevator can also dry and cool materials. ZC vertical elevator has two structures: trough type and closed type. According to different process requirements, it can design a screening elevator for material particle classification and an elevator for flammable and explosive materials.


    2. Main features:

    The product has a small footprint and is convenient for process layout.

    Materials can be conveyed upwards or downwards.

    Low noise, simple structure, convenient installation and maintenance.

    The structure is simple and reasonable, energy consumption is small, electric energy is saved, and trough wear is small.


    TypeLifting Capability(t/h)

    Diameter of spiral chute

    (mm)

    Lifting height

    (m)

    Speed

    (rpm)

    Double amplitude

    (mm)

    Power

    (kw)

    Weight

    (kg)

    ZC300-1.0300≤2.09606-72*0.4800
    ZC500-2.0500≤3.09606-82*0.751150
    ZC550-3.0550≤3.59606-82*1.51300
    ZC600-3.0600≤4.09606-72*1.51500
    ZC800-4.0800≤4.59606-82*2.21750
    ZC850-4.0850≤5.09606-92*2.22300
    ZC900-3.5900≤6.09606-92*3.02600
    ZC950-4950≤8.09606-92*3.73200

    Vertical Spiral Elevator Conveyor , Spiral Cooling Conveyor For Rock Salt
