    High Altitude Climbing Truck 12m Hydraulic Scissor Lift Platform

    Ask Lasest Price
    Brand Name : KN
    Model Number : SJY
    Certification : CE,ISO
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 1000pcs
    Delivery Time : 15 work,days
    • Product Details
    • Company Profile

    High Altitude Climbing Truck 12m Hydraulic Scissor Lift Platform

    Platform Lift Clipping Fork Type Mobile Small Hydraulic Lifting Platform High-Altitude Climbing Truck


    Standard Features:

    With CE certification,meet EN 1570 ANSI/ASME safety standards.


    Convenient electric and hydraulic system and scissor design for easy lifting,lowering.


    AC 110/220/380/460V,50/60Hz power supply,low-tention (24V) control box.


    Applicable to various industries,expecially in warehousing,logistics,manufacturing industies.


    Custom design and specs available.


    FAQ

    1. Loading capacity----200KG, 250KG OR 300KG......?


    2. The size of the table-----?


    3. Working height------3m, 6m, 10m, 12m......?


    4. Driving mode ----Diesel engine or Hydraulic or Electric or Battery ?


    5. Fixed type (without wheel) or Trolley (with wheel) ?

    1. The lifting platform has been inspected and debugged at the factory before delivery. All the technical indexes have reached the design requirements. When using, the lifting platform only needs to be connected with the power supply, and the hydraulic system and electrical system need not to be adjusted.


    2. The platform should be carefully checked before use of hydraulic, electrical systems, no leakage or naked leakage before use.


    3. Lifting platform in use, the four legs should be firmly supported on a solid ground (with the wheel to leave the ground shall prevail) if necessary, the use of sleepers.


    4. Lifting platform empty run 1-3 times before loading operation.


    5. load center of gravity should be as far as possible in the center of the table.


    6. Guard railings at both ends of the movable door should be locked after the lock operation.

    ModelLifting heig(m)Capacity(kg)Table size(mm)Power
    SJY03-443002100*820380V/1.1KW
    SJY-03-663002100*820380V/1.1KW
    SJY-05-665002100*820380V/1.1KW
    SJY-03-883002100*900380V/1.5KW
    SJY-05-885002100*900380V/1.5KW
    SJY1-8810002100*1200380V/3KW
    SJY03-10103002100*1200380V/2.2KW
    SJY05-10105002100*1200380V/2.2KW
    SJY1-101010002100*1500380V/3KW
    SJY03-12123002550*1500380V/3KW
    SJY05-12125002550*1500380V/3KW
    SJY1-121210002550*1500380V/4KW
    SJY03-14143002900*1500380V/3KW
    SJY05-14145002900*1500380V/3KW
    SJY01-141410002900*1500380V/4KW
    SJY03-16163003000*1600380V/4KW
    SJY05-16165003000*1600380V/4KW
    SJY03-18183003200*1600380V/4KW
    SJY05-18185003200*1600380V/4KW
    SJY03-20203003200*1600380V/4KW
